Automatic Luxury Urine Bag Machine

Description：

- The machine speed is about400-500PCS / hour, which requires only one worker to operate.

- The total power is 20kW, and the air pressure can be 6-8kg.

- Machine size: 1300x3200x1900mm, weight is about5000 kg.

- The inlet (including counter-current film) and outlet pipes are automatically welded on one machine.

- Automatic urine bag forming machine, including automatic printing, welded tube, welded reflux film, welded bag body, cutting, etc.

- PLC control system, touch screen interface, simple operation and easy to use, with counting function for user to set output.

- The fault alarm system can be displayed on the touch screen for quick troubleshooting.

- The water circulation constant temperature system ensures that the mold is at a constant temperature and makes the urine bag welding process consistent.

- Stainless steel frame to meet the production requirements of medical bag purification workshop.

Configuration：

- Electrical control box

- Double turntable feeding device, roll material on roller

- A backflow prevention film device, 2 roll film.

- Double high frequency welding device, one for urine bag body tube welding and one for reverse reflow welding.

- Cutting device for cutting bag

- Photoelectric sensor for film positioning

- Programmable controller touch screen control

Machine Parameters:

Major Accessory Brands:
